| Wire Dia. in SWG/mm |
32-10 |
| Least Count of a turn |
0.1 |
| Winding Width (mm) |
0.1-350 |
| Centre height /Max.coil Height (mm) |
150- 1000 |
| Maximum Spindle speed |
350 TPM/RPM |
| Spindle motor |
3 HP , 3 phase geared with VFD drive |
| Traverse motor |
13.5 kg-cm , Bipolar stepper motor |
| Controller |
High performance ATMEL Microcontroller |
| Programming console |
Tactile key pad with LCD display |
| Programmable parameters |
Winding turns, wire diameters , coil width , speed etc |
| Power source |
Single phase 220 VAC / 3 Phase 385/415VAC |
| Machine Weight |
400 kg approx |
| Machine Dimensions in mm |
1250*1400*1600 Approx. |
| Price |
1250000 INR |
